E-bike

UI/Remote

Mastermind TCU, 2.2″ high resolution screen, fully customizeable with Specialized app, works with Apple Find My

Motor

Specialized 3.1 Motor, 105Nm torque, 810W power

Charger

Specialized 4amp charger

Battery

Specialized Turbo X2 840Wh integrated battery pack

Frameset

Seat Binder

Alloy, 38.6mm

Frame

Levo 4 carbon frame, 150mm travel, w/SWAT storage, side entry battery, fork travel up to 180mm, adjustable head angle, BB height, chainstay length

Suspension

Fork

FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset

Rear Shock

Fox FLOAT X Genie, Performance series, 210×55, Low speed rebound adjust, climb switch

Brakes

Front Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor

Rear Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor

Drivetrain

Cassette

SRAM 12-speed,10-52t

Chainrings

SRAM 34t T-Type chainring, 104 BCD, steel

Shift Levers

SRAM AXS Pod Controller w/discrete clamp

Chain

SRAM GX Eagle Transmission 12-Speed Flattop Chain

Crankset

SRAM S1000 Alloy crank, ISIS interface, 155mm length

Rear Derailleur

SRAM S1000 Eagle AXS

Wheels & tires

Rear Tire

Butcher GRID Gravity Radial T9 TLR Enduro Tire 27.5×2.4

Front Tire

Butcher GRID Gravity Radial T9 TLR Enduro Tire 29×2.4

Spokes

DT Swiss Elemental

Front Hub

Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h

Rear Hub

Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12x148mm thru-axle, 32h, HG Steel Fhb

Rims

Specialized, hookless alloy, 30mm inner width, tubeless ready

Inner Tubes

Standard, Presta Valve

Cockpit

Stem

Alloy Trail Stem, 35mm bar bore

Handlebars

Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise

Saddle

Bridge Comp, Hollow Cr-mo rails 155/143

Grips

Specialized Trail Grips

Seatpost

Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 150mm, S3: 170mm, S4: 200mm, S5-S6: 230mm

Accessories

SWAT

SWAT Internal downtube storage

Product details

Product ID

263410

Compliance Certification

As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. <br>For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fdny/batteries)

Weight

Weight

24.54 kg (54 lb, 1.6 oz)

Weight Size

S4
