E-bike

UI/Remote

Mastermind TCU, 2.2″ high resolution screen, fully customizeable with Specialized app, works with Apple Find My

Motor

Specialized 3.1 Motor, 105Nm torque, 810W power

Charger

Specialized 4amp charger

Battery

Specialized Turbo X2 840Wh integrated battery pack

Frameset

Seat Binder

Alloy, 38.6mm

Frame

Levo 4 carbon frame, 150mm travel, w/SWAT storage, side entry battery, fork travel up to 180mm, adjustable head angle, BB height, chainstay length

Suspension

Rear Shock

All New Rockshox Super Deluxe Ultimate GENIE, RC2T damper with (LSC) Low Speed Compression and (HSC) High Speed Compression, GENIE adjustable airspring, rebound adjust, 210x55mm

Fork

All New SRAM FS ZEB Ultimate, 29″ 160mm, Linear XL spring with ButterCups and adjustable bottom out, new Charger 3.2 damper with HSC and LSC, rebound adjust

Brakes

Front Brake

SRAM Maven Silver, 4-piston caliper, hydraulic disc, 220mm rotor

Rear Brake

SRAM Maven Silver, 4-piston caliper, hydraulic disc, 220mm rotor

Drivetrain

Chainrings

SRAM 34t T-Type chainring, 104 BCD, steel

Shift Levers

SRAM AXS Pod Controller w/discrete clamp

Crankset

SRAM XO Alloy crank, 155mm, ISIS interface

Rear Derailleur

SRAM X0 Eagle Transmission

Chain

SRAM X0 Eagle Transmission 12-Speed Flattop Chain

Cassette

SRAM XS 1295, 12 speed, 10-52

Wheels & tires

Rear Tire

Butcher GRID Gravity Radial T9 TLR Enduro Tire 27.5×2.4

Front Tire

Butcher GRID Gravity Radial T9 TLR Enduro Tire 29×2.4

Inner Tubes

Standard, Presta Valve

Rear Wheel

Traverse HD Carbon 27.5″ rim, DT Swiss 350 hub, 30mm inner width, 32H, 12x148mm

Front Wheel

Traverse HD Carbon 29″ rim, DT Swiss 350, 30mm inner width, 28H, 15x110mm

Cockpit

Seatpost

Bike Yoke, Revive Max 3.0, 34.9, S1: 125mm, S2: 160mm, S3-S4: 185mm, S5-S6: 213mm

Saddle

Bridge Expert with MIMIC, Hollow Ti rails

Grips

Deity Lockjaw, Lock On, 32mm OD, 133mm Length, Black

Handlebars

RaceFace Era Carbon Handlebars, 35mm clamp, back-sweep 8-degrees, up-sweep 5 degrees, 800mm width, S1/S2: 40mm rise, S3-S6: 55mm rise

Stem

RaceFace, 35mm clamp, 40mm length

Accessories

SWAT

SWAT Internal downtube storage

Product details

Product ID

263400

Compliance Certification

As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. <br>For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fdny/batteries)

Weight

Weight

24.28 kg (53 lb, 8.5 oz)

Weight Size

S4
